Drawing / Dimension / Request for quotation
To request a quotation, check the RFQ column for any product(s) you would like a quotation for.
The product(s) you select will be added to the quotation request list.
| RFQ | Drawing | No. | List Price | Size | L(mm) | B(mm) | P(mm) | H(mm) | t(mm) | D(mm) | D1(mm) | Hole dia.(mm) | Unit Weight(g) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AK3769 | $138.30 | 125 | 80 | 125 | 55 | 125 | 6 | 42.7 | 16 | 10 | 820 | |
|
|
AK3770 | $195.50 | 150 | 100 | 150 | 70 | 150 | 6 | 48.6 | 19 | 11 | 1300 | |
|
|
AK3771 | $374.50 | 200 | 140 | 200 | 110 | 200 | 9 | 60.5 | 25 | 11 | 3300 | |
|
|
AK3772 | $597.00 | 250 | 190 | 250 | 150 | 250 | 10 | 76.3 | 28 | 13 | 5800 | |
|
|
AK3773 | $867.50 | 300 | 200 | 300 | 160 | 300 | 12 | 89.1 | 32 | 13 | 8500 |
