Drawing / Dimension / Request for quotation
To request a quotation, check the RFQ column for any product(s) you would like a quotation for.
The product(s) you select will be added to the quotation request list.
| RFQ | Drawing | No. | List Price | Size(Pipe dia.)(mm) | Type | H(mm) | A(mm) | B(mm) | B1(mm) | D(mm) | D1(mm) | P(mm) | P1(mm) | Wood screw | Unit Weight(g) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AK2480 | $23.90 | 19 | End | 42 | 23.3 | 32 | 15 | 48 | 24 | 34 | 13 | φ3.5 | 70 | |
|
|
AK2490 | $20.90 | 19 | Through | 42 | 23.3 | 20 | - | 48 | 24 | 34 | 13 | φ3.5 | 60 | |
|
|
AK2481 | $39.80 | 25 | End | 47 | 29.5 | 42 | 18 | 54 | 30 | 40 | 16 | φ3.5 | 120 | |
|
|
AK2491 | $32.00 | 25 | Through | 47 | 29.5 | 26 | - | 54 | 30 | 40 | 16 | φ3.5 | 100 | |
|
|
AK2482 | $70.50 | 32 | End | 66 | 37.4 | 55 | 25 | 64 | 40 | 48 | 20 | φ4.1 | 230 | |
|
|
AK2492 | $60.20 | 32 | Through | 66 | 37.4 | 32 | - | 64 | 40 | 48 | 20 | φ4.1 | 180 | |
|
|
AK2483 | $98.50 | 38 | End | 79 | 43.4 | 65 | 30 | 70 | 40 | 54 | 20 | φ4.1 | 300 | |
|
|
AK2493 | $75.50 | 38 | Through | 79 | 43.4 | 34 | - | 70 | 40 | 54 | 20 | φ4.1 | 230 | |
|
|
AK2488 | $141.70 | 42.7 | End | 87.4 | 48.1 | 74 | 32 | 76 | 44 | 60 | 24 | φ4.1 | 380 | |
|
|
AK2498 | $108.50 | 42.7 | Through | 87.4 | 48.1 | 42 | - | 76 | 44 | 60 | 24 | φ4.1 | 300 | |
|
|
AK2484 | $181.40 | 50 | End | 103 | 55.4 | 86 | 34 | 82 | 50 | 66 | 30 | φ4.1 | 560 | |
|
|
AK2494 | $146.90 | 50 | Through | 103 | 55.4 | 52 | - | 82 | 50 | 66 | 30 | φ4.1 | 460 |
