Drawing / Dimension / Request for quotation
To request a quotation, check the RFQ column for any product(s) you would like a quotation for.
The product(s) you select will be added to the quotation request list.
| RFQ | Drawing | No. | List Price | Size(mm) | d(mm) | D(mm) | Unit Weight(g) | Work Load Limit(kg) |
|---|---|---|---|---|---|---|---|---|
|
AK7000 | $1.10 | 3*20 | 3 | 20 | 4 | 20 | |
|
|
AK7001 | $1.20 | 3*25 | 3 | 25 | 5 | 20 | |
|
|
AK12500 | $1.30 | 3*30 | 3 | 30 | 6 | 15 | |
|
|
AK12501 | $1.50 | 3*35 | 3 | 35 | 7 | 12 | |
|
|
AK12502 | $1.60 | 3*40 | 3 | 40 | 8 | 10 | |
|
|
AK12504 | $2.00 | 3*50 | 3 | 50 | 10 | 5 | |
|
|
AK7002 | $1.40 | 4*22 | 4 | 22 | 8 | 40 | |
|
|
AK7003 | $1.50 | 4*25 | 4 | 25 | 9 | 40 | |
|
|
AK7004 | $1.60 | 4*30 | 4 | 30 | 11 | 40 | |
|
|
AK7005 | $1.90 | 4*35 | 4 | 35 | 12 | 40 | |
|
|
AK12510 | $2.10 | 4*40 | 4 | 40 | 14 | 30 | |
|
|
AK12511 | $2.30 | 4*45 | 4 | 45 | 15 | 20 | |
|
|
AK12512 | $2.40 | 4*50 | 4 | 50 | 17 | 20 | |
|
|
AK12513 | $2.60 | 4*55 | 4 | 55 | 18 | 15 | |
|
|
AK12514 | $2.80 | 4*60 | 4 | 60 | 20 | 15 | |
|
|
AK12528 | $2.00 | 5*20 | 5 | 20 | 12 | 60 | |
|
|
AK7006 | $2.30 | 5*26 | 5 | 26 | 15 | 60 | |
|
|
AK7007 | $2.40 | 5*30 | 5 | 30 | 17 | 60 | |
|
|
AK7008 | $2.50 | 5*35 | 5 | 35 | 20 | 60 | |
|
|
AK7084 | $2.70 | 5*40 | 5 | 40 | 22 | 60 | |
|
|
AK12520 | $3.40 | 5*45 | 5 | 45 | 25 | 50 | |
|
|
AK12521 | $3.60 | 5*50 | 5 | 50 | 27 | 40 | |
|
|
AK12522 | $3.70 | 5*55 | 5 | 55 | 29 | 30 | |
|
|
AK12523 | $3.80 | 5*60 | 5 | 60 | 31 | 20 | |
|
|
AK12525 | $4.00 | 5*70 | 5 | 70 | 36 | 15 | |
|
|
AK7009 | $2.60 | 6*30 | 6 | 30 | 26 | 80 | |
|
|
AK7010 | $2.80 | 6*35 | 6 | 35 | 29 | 80 | |
|
|
AK7011 | $3.00 | 6*40 | 6 | 40 | 33 | 80 | |
|
|
AK7020 | $3.20 | 6*45 | 6 | 45 | 36 | 80 | |
|
|
AK12530 | $3.60 | 6*50 | 6 | 50 | 40 | 70 | |
|
|
AK12531 | $4.30 | 6*60 | 6 | 60 | 47 | 60 | |
|
|
AK12532 | $4.70 | 6*70 | 6 | 70 | 54 | 50 | |
|
|
AK12533 | $5.20 | 6*80 | 6 | 80 | 61 | 40 | |
|
|
AK7012 | $4.10 | 7*45 | 7 | 45 | 50 | 100 | |
|
|
AK7013 | $5.00 | 8*40 | 8 | 40 | 61 | 120 | |
|
|
AK7014 | $5.20 | 8*45 | 8 | 45 | 66 | 120 | |
|
|
AK12548 | $5.90 | 8*50 | 8 | 50 | 72 | 120 | |
|
|
AK7015 | $6.10 | 8*55 | 8 | 55 | 80 | 100 | |
|
|
AK12540 | $6.60 | 8*60 | 8 | 60 | 86 | 100 | |
|
|
AK12541 | $8.00 | 8*70 | 8 | 70 | 99 | 80 | |
|
|
AK7016 | $7.60 | 9*50 | 9 | 50 | 94 | 180 | |
|
|
AK7017 | $8.30 | 9*60 | 9 | 60 | 110 | 150 | |
|
|
AK12550 | $9.90 | 9*70 | 9 | 70 | 126 | 120 | |
|
|
AK12551 | $10.30 | 9*80 | 9 | 80 | 142 | 100 | |
|
|
AK12554 | $11.80 | 10*50 | 10 | 50 | 117 | 200 | |
|
|
AK7060 | $13.00 | 10*55 | 10 | 55 | 128 | 200 | |
|
|
AK12555 | $13.60 | 10*60 | 10 | 60 | 138 | 200 | |
|
|
AK7061 | $14.30 | 10*65 | 10 | 65 | 148 | 180 | |
|
|
AK7062 | $16.20 | 10*80 | 10 | 80 | 177 | 150 | |
|
|
AK12559 | $18.70 | 10*100 | 10 | 100 | 213 | 100 | |
|
|
AK12560 | $18.20 | 12*50 | 12 | 50 | 176 | 400 | |
|
|
AK7063 | $18.90 | 12*55 | 12 | 55 | 190 | 350 | |
|
|
AK7064 | $21.50 | 12*70 | 12 | 70 | 233 | 300 | |
|
|
AK7065 | $27.80 | 12*100 | 12 | 100 | 318 | 250 | |
|
|
AK7066 | $37.90 | 12*125 | 12 | 125 | 389 | 200 | |
|
|
AK12565 | $24.70 | 13*60 | 13 | 60 | 244 | 550 | |
|
|
AK7067 | $26.40 | 13*75 | 13 | 75 | 293 | 500 | |
|
|
AK7068 | $29.70 | 13*100 | 13 | 100 | 377 | 450 | |
|
|
AK7069 | $34.70 | 13*120 | 13 | 120 | 443 | 380 | |
|
|
AK12570 | $43.60 | 16*70 | 16 | 70 | 435 | 800 | |
|
|
AK7070 | $45.70 | 16*85 | 16 | 85 | 510 | 700 | |
|
|
AK7071 | $50.80 | 16*100 | 16 | 100 | 586 | 600 | |
|
|
AK7072 | $56.30 | 16*120 | 16 | 120 | 686 | 450 | |
|
|
AK7073 | $65.60 | 16*150 | 16 | 150 | 838 | 400 | |
|
|
AK7074 | $77.20 | 19*100 | 19 | 100 | 678 | 900 | |
|
|
AK7075 | $99.90 | 19*130 | 19 | 130 | 1060 | 700 | |
|
|
AK7076 | $107.60 | 19*145 | 19 | 145 | 1167 | 600 | |
|
|
AK7077 | $115.20 | 19*160 | 19 | 160 | 1274 | 550 | |
|
|
AK12580 | $127.50 | 22*100 | 22 | 100 | 1166 | 1350 | |
|
|
AK7078 | $135.40 | 22*120 | 22 | 120 | 1355 | 1250 | |
|
|
AK7079 | $149.70 | 22*150 | 22 | 150 | 1641 | 1000 | |
|
|
AK7080 | $177.50 | 22*170 | 22 | 170 | 1832 | 850 | |
|
|
AK12585 | $208.20 | 25*100 | 25 | 100 | 1542 | 1750 | |
|
|
AK7081 | $232.40 | 25*150 | 25 | 150 | 2157 | 1500 | |
|
|
AK7082 | $247.00 | 25*175 | 25 | 175 | 2465 | 1250 | |
|
|
AK7083 | $256.60 | 25*200 | 25 | 200 | 2773 | 1100 | |
|
|
AK12590 | $321.40 | 28*150 | 28 | 150 | 2755 | 1750 | |
|
|
AK12591 | $363.00 | 28*200 | 28 | 200 | 3528 | 1500 | |
|
|
AK12595 | $590.40 | 32*200 | 32 | 200 | 4689 | 2000 | |
|
|
AK12596 | $635.50 | 32*250 | 32 | 250 | 5700 | 1750 |
